2MP Wide Angle OV2740 Sensor Medical Endoscope Camera Module With Usb 2.0 Uvc
Guangzhou Sincere Information Technology Ltd. is one of the most professional 2mp wide angle ov2740 sensor medical endoscope camera module with usb 2.0 uvc manufacturers and suppliers in China. Welcome to wholesale discount products for sale here from our factory. Customized orders are welcome.
This Endoscope Camera Module featuring the Sony Sensor OV2740 , This Wide Angle Camera Module is designed with an view angle of 140°, ensuring that doctor can capture a comprehensive field of view during examinations and procedures. With a focal length of just 1.05mm, this 2MP Camera Module delivers high-resolution imagery while maintaining a close range focus, effectively ranging between 8mm and 80mm.
One of the standout features of this Medical Endoscope Camera Module is its low TV distortion, measured at less than -50%, which ensures that the images captured are true to life and highly accurate,and the USB 2.0 UVC technology ease of use across various devices,very convenient.


1.Field of View: With a wide viewing angle of 140°.
2.Imaging Performance: The module is built around the sony OV2740 sensor
3.Focusing Capabilities: The focusing range of 8-80mm allows for flexibility in capturing images at varying distances.
4.Low Distortion: The TV distortion is less than -50%.
Application of Endoscope Camera Module
- Medical: Minimally invasive procedures and diagnostics.
- Industrial: Inspection of hard-to-reach areas in machinery.
- Education: demonstrations in anatomy








Product Details
|
Model Number |
SF-C2016USB-1080P60-D5 |
|
Sensor Type |
OV2740 |
|
Connector |
Micro USB-5P |
|
FOV(D) |
140° |
|
F.NO |
5.9 |
|
TV Distortion |
<-50% |
|
Focal Length |
1.05mm |
|
inteface |
USB2.0 |
|
Focusing Range |
8-80mm |
|
Array Size |
1920x1080 |
|
Sensor Size |
1/6 inch |
SINCEREFIRST camera module manufacturing enterprise integrates design, development, manufacturing and sales. We can supply ready made 0.3mp to 108mp FPC & USB camera module and diameter 0.9mm~8.0mm endoscope camera module. Our products are widely used in various fields, such as AIoT equipment, smart home, smart medical, intelligent transportation, automatic driving, intelligent security, Intelligent warehousing, scanning, robot, UAV, medical endoscope, industrial endoscope, computer, intelligent terminals etc.
If you are looking for camera module or camera sensor manufacturers and suppliers, please feel free to contact us for camera module price and more detailed introduction. SINCEREFIRST is a leading high-tech company specializing in integrated optical device manufacturers and optical imaging system solution providers. There are different types of camera modules and camera sensors for sale, and they also support customization to meet all your needs and solve your problems.
