OV5640 5MP MIPI Camera Module
video

OV5640 5MP MIPI Camera Module

This mipi camera module is based on OmniVision OV5640 CMOS Image Sensor, the cost-effective CMOS imaging solution that enables high-speed image capture capabilities, and includes variable functions, such as gain, frame rate, and exposure while maintaining low power consumption.
Send Inquiry
Product Introduction

Guangzhou Sincere Information Technology Ltd. is one of the most professional ov5640 5mp mipi camera module manufacturers and suppliers in China. Welcome to wholesale discount products for sale here from our factory. Customized orders are welcome.





Introduction:

This mipi camera module is based on OmniVision OV5640 CMOS Image Sensor, the cost-effective CMOS imaging solution that enables high-speed image capture capabilities, and includes variable functions, such as gain, frame rate, and exposure while maintaining low power consumption. The sensor has a 1/4 Inch optical format, which combines with the pixel size of 1.4um(H) x 1.4um(V), resulting in the 5.0 Megapixel support at 30 fps 2592H x 1944V for maximum video performance.

product-750-731



Features:





•Omnivision OV5640 Image Sensor with pixel size of 1.4µm

•Electronic Rolling Shutter

•Image Area - 3673.6 µm x 2738.4 µm

•Focus Distance: 5m

•5MP resolution with Omnivision OV5640 CMOS image sensor

•Fixed Focus/Manually adjustable

•High quality image, high sensitivity

•Small dimension for embedded application

•Flexible and adjustable, fits well with any of your products



Application of Camera Module:




•Biometrics (IRIS Scan)

•Electronic Microscope

•Camera for handhelds / Tablets

•Surveillance

•OCR readers

Product Details:




Sensor Type

OV5640

Focusing Distance

5m

Focal Length

6.0mm

F Number

2.0

Fov(H*V)

36°*25°

F.NO

2.0

TV Distortion

-2%

Test Connector

FH12-24S-0.5SH

Output Format

YUV output



SINCEREFIRST camera module manufacturing enterprise integrates design, development, manufacturing and sales. We can supply ready made 0.3mp to 108mp FPC & USB camera module and diameter 0.9mm~8.0mm endoscope camera module. Our products are widely used in various fields, such as AIoT equipment, smart home, smart medical, intelligent transportation, automatic driving, intelligent security, Intelligent warehousing, scanning, robot, UAV, medical endoscope, industrial endoscope, computer, intelligent terminals etc.

If you are looking for camera module or camera sensor manufacturers and suppliers, please feel free to contact us for camera module price and more detailed introduction. SINCEREFIRST is a leading high-tech company specializing in integrated optical device manufacturers and optical imaging system solution providers. There are different types of camera modules and camera sensors for sale, and they also support customization to meet all your needs and solve your problems.
