Guangzhou Sincere Information Technology Ltd. is one of the most professional Miniature Sony IMX686 64MP D-PHY MIPI Auto Focus Camera Module manufacturers and suppliers in China. Welcome to wholesale discount products for sale here from our factory. Customized orders are welcome.
A miniature camera module is useful only when its interface and optical structure match the space and host architecture available inside the device. This IMX686 configuration is designed as the D-PHY option within SincereFirst's 64MP IMX686 camera range, giving compact OEM and IoT systems a defined alternative to the 30Pin C-PHY version.
The module uses a 34Pin 4-Lane D-PHY MIPI interface together with VCM Auto Focus from 10 cm to Infinity. It provides 9248 × 6944 native resolution, 4K@30FPS output, PDAF, HDR and RAW imaging, while the D78° × H66° × V52° optical configuration keeps TV distortion below 1%. Standard production uses SincereFirst's in-house Active Alignment process.
Features:
• Miniature IMX686 Module Structure
The module combines the 64MP IMX686 sensor with a compact FPC camera structure for embedded devices where installation space and camera routing need to be considered together.
• 34Pin 4-Lane D-PHY MIPI
This model uses a defined 34Pin 4-Lane D-PHY interface rather than presenting both C-PHY and D-PHY as generic sensor capabilities.
• Low-Distortion D78° Optics
The lens provides D78° × H66° × V52° coverage with TV distortion below 1%, supporting applications where image geometry matters as well as resolution.
• VCM Auto Focus from 10 cm to Infinity
The Auto Focus structure supports subject-distance changes from 10 cm to Infinity, giving compact devices more flexibility than a preset Fixed Focus configuration.
• 64MP, PDAF and HDR Imaging
The IMX686 provides 9248 × 6944 native resolution and supports PDAF, HDR and 4-in-1 pixel operation for high-resolution embedded imaging.
• Standard Active Alignment Production
This model is produced with SincereFirst's in-house Active Alignment process as part of the standard camera module assembly route.
Application of MIPI Camera Module
• Compact IoT Imaging Devices
The miniature structure, D-PHY interface and Auto Focus configuration can support connected imaging devices where camera space and host integration are tightly constrained.
• Kiosk and Access Terminals
The 64MP sensor and variable-distance focusing can support kiosk scanners, access terminals and other compact front-facing imaging systems.
• Embedded Scanning Equipment
Low distortion and Auto Focus make the module suitable for compact scanning and visual capture equipment where subject distance and image geometry may vary.
• Compact Recognition and Monitoring Terminals
The D-PHY route can be evaluated for embedded recognition or monitoring devices that need a high-resolution camera without adopting the C-PHY configuration.
Product Details
|
Product Name |
64MP 30Pin D-PHY MIPI Camera Module |
|
Sensor |
Sony IMX686 CMOS Sensor |
|
Pixel |
64MP |
|
Resolution |
9428x6944 |
|
Frame Rate |
4K@30FPS |
|
Sensor Size |
1/1.73 Inch |
|
Feature |
PDAF, HDR, 4-in-1 Pixel |
|
Output Format |
RAW |
|
Focusing Range |
10cm ~ Infinity |
|
EFL |
5.563mm |
|
F.NO |
1.8 |
|
FOV |
D78°*H66°*V52° |
|
Focus Type |
VCM Auto Focus |
|
TV Distortion |
＜1% |
|
Process |
Active Alignment (AA) Process - standard production |
|
Interface |
34Pin BTB 4-Lane D-PHY MIPI Interface |
Customization Options
D-PHY Host Integration
The processor, CSI/MIPI interface and 34Pin connector route can be reviewed before the module is finalized for the target device.
FPC and Mechanical Matching
FPC routing and module placement can be discussed for compact devices where the camera must fit within a restricted enclosure or board layout.
Lens and FOV Configuration
The standard D78° × H66° × V52° optics can be reviewed when the final device requires different scene coverage or optical geometry.
Auto Focus Configuration
The VCM focusing behavior can be evaluated around the actual working-distance requirements of the device.
AA for Related Camera Designs
This model uses Active Alignment as standard production. AA can also be applied to other suitable camera modules when additional optical alignment control is required.
FAQ
Q: When should I choose this D-PHY IMX686 camera module instead of the C-PHY version?
A: Choose this model when the host platform requires a D-PHY camera interface or when the 34Pin D-PHY structure better matches the target device. The C-PHY version is intended for a different host integration route.
Q: What makes this a miniature IMX686 camera module?
A: It combines the IMX686 sensor, lens, VCM Auto Focus and 34Pin D-PHY interface in a compact FPC camera structure intended for embedded OEM devices.
Q: What are the main Sony IMX686 specifications?
A: The module uses a 64MP Sony IMX686 sensor with 9248 × 6944 native resolution, a 1/1.73-inch sensor format and 0.8 μm pixels.
Q: Does this module use C-PHY or D-PHY?
A: This specific camera module uses a 34Pin 4-Lane D-PHY MIPI interface. C-PHY support should not be presented as the interface of this product.
Q: What is the Auto Focus range?
A: The confirmed VCM Auto Focus range is 10 cm to Infinity.
Q: What is the optical distortion?
A: The confirmed TV distortion is below 1%, with a D78° × H66° × V52° field of view.
Q: Can the FPC, connector or optics be customized?
A: Yes. FPC routing, connector requirements and optical configuration can be discussed according to the target device.
Q: Can I request a sample for an IoT or embedded device project?
A: Yes. A sample can be used to evaluate D-PHY compatibility, Auto Focus behavior, image coverage and mechanical integration before production.
Need a D-PHY IMX686 Camera for a Compact Device?
If your device requires IMX686 image detail but uses a D-PHY host interface, SincereFirst can help review the 34Pin connection, available installation space and focusing requirements. If your host instead uses C-PHY, the 30Pin IMX686 version can be evaluated as the alternative route.
