The sony starvis imx290 sensor is CMOS active pixel type solid-state image sensor with a square pixel array and 2.13 M effective pixels. This sensor has low power consumption. High sensitivity, low dark current and no smear are achieved through the adoption of R, G and B primary color mosaic filters.

Send Inquiry

Product Introduction

Guangzhou Sincere Information Technology Ltd. is one of the most professional sony imx290 camera manufacturers and suppliers in China. Welcome to wholesale discount products for sale here from our factory. Customized orders are welcome.

Introducing the Sony IMX290 Camera - A High-Quality Camera with Exceptional Features!

Are you looking for a cutting-edge camera that delivers outstanding image quality and performance? If yes, look no further than the Sony IMX290 Camera!

Manufactured by Sony, the IMX290 is a highly advanced camera that boasts a range of exceptional features and performance capabilities. These features and capabilities place this camera at the forefront of the industry and make it one of the most sought-after cameras in the market.

To give you an overview of this product's features, we'll explore the following:

- The Sony IMX290 Camera's impressive sensor

- Highlight on its image quality

- Comprehensive video recording capabilities

- Size and performance details

- The benefits of incorporating this camera in your marketing strategy

- Assurance of quality and reliability

- Conclusion

The Sony IMX290 Camera's Impressive Sensor:

One of the core features that make the Sony IMX290 camera stand out is its sensor. The camera boasts an Exmor R CMOS sensor that offers superlative performance, remarkable sensitivity, and a speedy processing rate. This high-end sensor is the pride of the Sony family cameras and features unsurpassed image quality and advanced features that make it ideal for a wide range of applications.

Highlight on its Exceptional Image Quality:

When it comes to image quality, the Sony IMX290 camera does not disappoint. This camera delivers outstanding image quality with a resolution of 2.13 megapixels. With its advanced features, such as the High Dynamic Range (HDR) technology and the Back-Illuminated Sensor (BSI), the camera produces vivid, sharp, and detailed images.

Additionally, the BSI technology protects the camera from ghosting effects, which makes it an ideal tool for capturing fast-moving objects or scenes. The advanced features boost the Sony IMX290 camera's performance by offering exceptional low-light sensitivity, which helps preserve the detail of images in low-light conditions.

Comprehensive Video Recording Capabilities:

The Sony IMX290 camera delivers impressive video recording capabilities of 1080p HD quality at 60 frames per second. The camera features a unique image-stabilization technology, which makes it ideal for recording high-quality videos in high-motion surround environments. Additionally, the camera boasts a startup time of fewer than two seconds, which means that you can begin recording your videos in no time.

Size and Performance Details:

The Sony IMX290 Camera is lightweight and compact, making it travel-friendly and easy to use. The camera has a size of 8.5mm x 9.9mm and weighs approximately 1.2 grams. It provides exceptional performance – even in the most challenging of conditions – and features a digital output interface ideal for high-speed transmission for faster data transfers.

The Benefits of Incorporating This Camera In Your Marketing Strategy:

The Sony IMX290 Camera is an ideal camera for a business that specializes in producing marketing content. The camera's exceptional video and image quality, high-speed processing, high sensitivity to low-light conditions, and image stabilization technology provide businesses with all the tools they need to produce compelling marketing content that will captivate their audience.

This camera emphasizes a business's commitment to innovation, professionalism, and staying ahead of the curve. When incorporated into marketing activities, it gives a business a competitive edge over other businesses using other standard quality cameras in the market. Additionally, business owners can promote their brand with excellent quality content, building trust and loyalty among their clients or customers.

Assurance of Quality and Reliability:

Our company manufactures premium quality products, and we are confident that our customers will appreciate the quality and reliability of our Sony IMX290 Camera. We use high-grade components to build the camera, and our rigorous manufacturing process ensures the quality of the camera.

Conclusion:

If you desire to capture high-quality images and videos with a cutting-edge camera, there is no better choice than the Sony IMX290 Camera. With its advanced features, high sensitivity, top-notch image processing capabilities, and exceptional video recording capabilities, this camera is arguably one of the best cameras in the market.

Our company understands how essential it is for businesses to have high-quality cameras for their marketing and promotional activities, and that's why we believe that our Sony IMX290 Camera is an ideal solution. Contact us today to acquire your Sony IMX290 Camera!

ODM/OEM CUSTOMIZED DESIGN IS WELCOME!

FEATURE 01

Best Quality Assurance

FEATURE 02

1 year Replacement!

FEATURE 03

10 years warranty!

The sony imx290 camera is a enbedded computer module.
This raspberry pi camera mipi captures uncompressed Full HD images at 120 fps frame rate, this 120fps module helps to minimize frame-to-frame distortion and reduce motion blur while capturing moving objects to produce crystal clear images with greater scene details.
And the sony imx290 camera is fixed focus with mipi interface, focusing range can be reached 50cm to infinity, which is bring the mipi camera board.
Like the sony imx290 camera module, the camera module with good imaging effect in low light is suitable for detection, detection and other applications where the environmental luminosity effect is not particularly good.

Introduction

The IMX290LQR-C is a diagonal 6.46 mm (Type 1/2.8) CMOS active pixel type solid-state image sensor with a square pixel array and 2.13 M effective pixels. This chip operates with analog 2.9 V, digital 1.2 V, and interface 1.8 V triple power supply, and has low power consumption. High sensitivity, low dark current and no smear are achieved through the adoption of R, G and B primary color mosaic filters. This chip features an electronic shutter with variable charge-integration time.

product-750-750

Features

• Ultra low light Sony STARVIS IMX290 sensor

• High Frame Rate: 120fps module

• Raspberry Pi Camera Mipi

• CMOS active pixel type dots

• Built-in timing adjustment circuit, H/V driver and serial communication circuit

• Input frequency: 74.25 MHz / 37.125 MHz

• Number of recommended recording pixels: 1920 (H) × 1080 (V) approx. 2.07M pixel

• Readout mode All-pixel scan mode 720p-HD readout mode Window cropping mode Vertical / Horizontal direction-normal / inverted readout mode

• Readout rate Maximum frame rate in Full HD 1080p mode: 120 frame / s

• Wide dynamic range (WDR) function Multiple exposure WDR Digital overlap WDR

• Variable-speed shutter function (resolution 1H units)

• 10-bit / 12-bit A/D converter

• Conversion gain switching (HCG Mode / LCG Mode)

• CDS / PGA function 0 dB to 30 dB: Analog Gain 30 dB (step pitch 0.3 dB) 30.3 dB to 72 dB: Analog Gain 30 dB + Digital Gain 0.3 to 42 dB (step pitch 0.3 dB)

• Supports I/O switching CMOS logic parallel SDR output Low voltage LVDS (150 m Vp-p) serial ( 2 ch / 4 ch / 8ch switching) DDR output CSI-2 serial data output ( 2 Lane / 4 Lane, RAW10 / RAW12 output)

• Recommended exit pupil distance: –30 mm to –∞

product-750-750

Application of Camera Module:

• Medical Imaging Equipment

• Night Vision Equipment

• Digital Cameras

• Scanners

• Bar Code Readers

• IOT Products

Product Details:

Sensor	IMX290LQR-C
Test Connector	FH12-30S-0.5SH
Focusing Range	50cm~Infinity
Focal Length	2.95±5%mm
F Number	2.5±5%
Fov(H)	80°
TV Distortion	＜-1%
Pinout	30pin
Output Format	RGB output

product-750-739

SINCEREFIRST camera module manufacturing enterprise integrates design, development, manufacturing and sales. We can supply ready made 0.3mp to 108mp FPC & USB camera module and diameter 0.9mm~8.0mm endoscope camera module. Our products are widely used in various fields, such as AIoT equipment, smart home, smart medical, intelligent transportation, automatic driving, intelligent security, Intelligent warehousing, scanning, robot, UAV, medical endoscope, industrial endoscope, computer, intelligent terminals etc.

If you are looking for camera module or camera sensor manufacturers and suppliers, please feel free to contact us for camera module price and more detailed introduction. SINCEREFIRST is a leading high-tech company specializing in integrated optical device manufacturers and optical imaging system solution providers. There are different types of camera modules and camera sensors for sale, and they also support customization to meet all your needs and solve your problems.

product-1267-713

FAQ

Q: What does a image sensor do?

A: However they are classified, the purpose of image sensors are the same; to convert incoming light (photons) into an electrical signal that can be viewed, analyzed, or stored. Image sensors are a solid-state device and serve as one of the most important components inside a machine vision camera.

Q: What are the two main types of image sensors?

A: Common Technology of Image Sensors

There are two major types of image sensors: CCD, or charge coupled device and CMOS, or complementary metal oxide semiconductor.

Q: How does an image sensor chip work?

A: Such chips contain large arrays of transistors, which in CMOS sensors are each composed of a photodiode and amplifier. The photodiodes accumulate electrical charge when exposed to light, and those charges are then converted to voltage, amplified and transmitted as electrical signals.

Q: What is CMOS image sensor made of?

A: Both CMOS and CCD imagers are constructed from silicon. This gives them fundamentally similar properties of sensitivity over the visible and near-IR spectrum. Thus, both technologies convert incident light (photons) into electronic charge (electrons) by the same photoconversion process.

Q: Why is image sensor size important?

A: The larger the sensor, the greater the surface area, the more light ( photons ) it will catch. Notice the massive difference in light collecting surface area between the APS-C vs full frame camera sensors. These cameras will produce much different overall image quality, with the larger far exceeding the smaller.

Q: What are image sensors used for?
