OV2312 2MP 60FPS Global Shutter USB Camera Module for Machine Vision Robot
video

OV2312 2MP 60FPS Global Shutter USB Camera Module for Machine Vision Robot

Capture color images at 1600×1300 and 60fps with the OV2312 global shutter sensor. This USB2.0 camera module supports machine vision projects that need object detail, color information, and consistent image geometry.
Send Inquiry
Product Introduction

Guangzhou Sincere Information Technology Ltd. is one of the most professional OV2312 2MP 60FPS Global Shutter USB Camera Module for Machine Vision Robot manufacturers and suppliers in China. Welcome to wholesale discount products for sale here from our factory. Customized orders are welcome.





Introduction:

A vision system may need to examine both an object's appearance and its position within a working area. This OV2312 camera module combines 2MP color imaging with a global shutter, providing image input for tasks such as robotic handling and multi-view inspection.



The 1600×1300 MJPG mode operates at 60fps. Fixed Focus optics and USB2.0 output support integration into dedicated equipment, while lens and optional industrial Shell configurations allow the camera assembly to be matched to the application.

Features


• 2MP Detail for Object Observation

The 1600×1300 image provides detail for observing component features, outlines, and surface appearance within the selected field of view.



• Global Shutter Image Geometry

The global shutter captures the image area together. It helps retain object geometry when the workpiece, camera, or supporting equipment is moving.



• Color Cues for Vision Processing

Color information can assist host software that distinguishes objects or evaluates their appearance. The camera supplies the image stream for the application's processing system.



• Optical and Mechanical Configuration Choices

Lens options and an optional industrial Shell support different working distances and mounting requirements. The camera module can be incorporated into a purpose-built vision assembly.

product-800-800



Application of USB Camera Module



• Robot Wrist Vision

Mount the camera within a robot vision assembly to observe parts, their orientation, and the surrounding work area. The color global shutter image supports host-side processing for picking, machine tending, or assembly tasks.



• Multi-View Foot Imaging

Use the module as an image acquisition component in a system that photographs a foot from several viewpoints. The images can support subsequent reconstruction and analysis in calibrated software, with the camera providing color and outline information.



• Grain Appearance Inspection

Capture grain color, outlines, and visible surface variations within the selected inspection area. The 2MP color image provides appearance information, while global shutter capture supports observation as material moves through the system.

product-750-598



product-800-800
product-800-800
product-800-800
product-800-800
product-800-800
product-800-800
product-800-800
product-800-800
product-800-800



Product Details




Product Name

2MP FHD 60FPS USB2.0 Camera Module

Image Sensor

OMNIVISION OV2312 monochrome CMOS Sensor

Pixel

2MP,1600x1300

Resolution

1600x1300@60FPS

Sensor Size

1/2.9 Inch

Output Formats

YUY2 / MJPG

Shutter

Global Shutter

Focus Type

Fixed Focus

Focusing Range

1cm–Infinity

Available Options

Industrial Shell and application-matched lenses

Interface

USB2.0

Module Size

38mm × 38mm



Customization Options





Optical Setup
Select lenses and applicable filters around the object size, working distance, and observation task.



Mechanical Assembly
Configure the optional industrial Shell, mounting arrangement, PCB, and cable requirements where applicable.



Software Connection
USB SDK support and product-specific Firmware or Driver work can support integration with the vision host.



Project Production
Coordinate configuration approval, certification requirements, supply arrangements, and warranty terms.



product-1267-713









FAQ





Q: When is the optional industrial Shell useful?

A: Choose a Shell configuration when the camera needs its own mounting assembly within the equipment. A Bare Module can be preferable when the equipment already provides the surrounding structure and the design needs more freedom in camera placement.

Q: Can this module support hardware-triggered acquisition?

A: Hardware-triggered capture requires a customized version. It should be selected as part of the project configuration when acquisition must follow an external equipment event.

Q: What turns several camera views into a 3D result?

A: A multi-view system needs suitable camera placement, calibration, and reconstruction software. This module provides the source images; the complete system determines the reconstruction and measurement performance.



Match the Camera Assembly to the Object and Task





SincereFirst supports camera module design and manufacturing for robotic and inspection equipment, including optical matching, mechanical configuration, and USB integration.
