Machine Vision Sony IMX415 STARVIS 8MP USB 3.0 Camera Module
This is a machine vision Sony IMX415 STARVIS 8MP USB3.0 camera module. At its core, it is equipped with the Sony IMX415 CMOS color image sensor, featuring 8MP effective pixels and capable of stably outputting 60FPS smooth images at 4K (3840×2160) resolution. The sensor size is 1/2.8 inch, with a pixel size of 1.45μm×1.45μm. It also supports Starvis low-light enhancement technology and HDR function, with a maximum dynamic range of 72dB. In terms of output formats, it is compatible with three mainstream formats: MJPG, YUY2, and H.264. For focusing performance, it supports manual adjustment with a range from 1cm (macro) to infinity. The lens is integrated with a 650nm IR filter, which works in conjunction with Starvis to optimize color reproduction. The module comes in two size options: 75mm×42mm with housing, and only 38mm×38mm without housing. It adopts a Type-C interface, supporting USB3.2 high-speed transmission rate and UVC universal video protocol. It is compatible with mainstream operating systems such as Raspberry Pi, Windows, Linux, and MacOS, and also provides an SDK development kit for secondary development. The power supply is via an external independent DC12V power source. The production process complies with SMT (ROHS) standards and AA manufacturing process, and the product has passed CE, FCC, RoHS, and Reach international inspections and certifications, ensuring both quality and environmental standards are met.
• Accurate Color Reproduction: Starvis technology enables clear color image capture in low-light environments close to 0.15 Lux, avoiding noise accumulation that plagues traditional cameras in low light. When paired with the 650nm IR filter, it accurately filters out infrared interference, preventing image color distortion in scenarios with complex lighting, achieving the dual effect of "no blurriness in low light and more realistic colors".
• Smooth Dynamic Images: 8MP pixels and 4K resolution ensure sharp image details, while the 60FPS high frame rate delivers smooth playback of dynamic scenes without freezes or motion blur, making it suitable for scenarios requiring high image coherence.
• Multi-Scenario Adaptive Imaging: The manual focusing design supports shooting from 1cm close-range (macro) to long-range monitoring at infinity. There is no need to replace the lens to meet imaging needs at close, medium, and long distances, adapting to various shooting scenarios.
• High-Speed Transmission & Plug-and-Play: The Type-C interface paired with USB3.2 rate enables lag-free and non-stuttering transmission of 4K images. It supports the UVC protocol for plug-and-play functionality, eliminating the need for complex driver installation. Additionally, it is compatible with multiple systems such as Raspberry Pi and Windows, lowering the threshold for use and development.
• Long-Term Stable Quality: Adopting SMT (ROHS) environmental protection process and AA manufacturing process ensures the module's precision and durability. It has passed international certifications like CE and FCC, allowing compliant use in multiple regions worldwide. The independent DC12V power supply prevents image flickering or system crashes caused by insufficient USB bus power, making it suitable for 24/7 continuous operation scenarios.
Application of USB Camera Module:
• Smart Retail Monitoring: Checkout counters often face alternating lighting and low-light environments at night. Starvis technology ensures clear recording of checkout operations at night without additional fill light. The 650nm IR filter prevents commodity color distortion caused by mixed lighting, and 4K resolution can clearly capture commodity barcodes and transaction details, facilitating loss prevention and transaction traceability.
• Home Smart Security: Home security needs to cope with night and daytime backlit scenarios. Starvis technology enables clear capture of facial outlines at night, while the 650nm IR filter prevents yellowish images under evening lighting. The 1cm macro function can capture details of courier packages at the door, and infinite focusing can cover the open area of the courtyard, balancing close-range identification and long-range monitoring.
• Industrial Equipment Inspection: When inspecting industrial equipment, it is often necessary to check the status of parts at close range. The 1cm macro focusing can clearly capture tiny defects. Low-light environments may exist inside equipment, and Starvis technology ensures clear visibility of details without additional fill light. The 650nm IR filter avoids image color distortion caused by interference from equipment indicator lights, improving inspection accuracy.
• Outdoor Live Streaming: Outdoor live streaming often encounters variable lighting conditions. Starvis technology maintains clear images in low-light environments such as under tree shade, and the 650nm IR filter restores the true colors of the scene. The USB3.2 high-speed transmission and Type-C portable interface are compatible with live streaming devices, and 4K@60FPS ensures smooth and detailed live streaming images.
• Smart Vending Cabinets: Used for commodity recognition and inventory management in new retail vending cabinets. Starvis technology addresses the challenge of uneven lighting inside the cabinets, and the 650nm IR filter ensures true color reproduction of commodity packaging, improving the accuracy of commodity recognition.
Product Details
|
Image Sensor |
Sony IMX415 CMOS Image Sensor |
|
Pixel |
8MP |
|
Keyword |
Sony IMX415 Starvis |
|
Resolution |
4K |
|
Sensor Size |
1/2.8 Inch |
|
Focusing Range |
1cm~Infinity |
|
Output Format |
MJPG/YUY2/H.264 |
|
Output Interface |
Type-C, USB3.2, UVC |
|
Pixel Size |
1.45μm*1.45μm |
|
Module Size |
38mm*38mm+75mm*42mm |
SINCEREFIRST camera module manufacturing enterprise integrates design, development, manufacturing and sales. We can supply ready made 0.1mp to 200mp FPC & USB camera module and diameter 0.9mm~10mm endoscope camera module. Our products are widely used in various fields, such as AIoT equipment, smart home, smart medical, intSSelligent transportation, automatic driving, intelligent security, Intelligent warehousing, scanning, robot, UAV, medical endoscope, industrial endoscope, computer, intelligent terminals etc.
If you are looking for camera module or camera sensor manufacturers and suppliers, please feel free to contact us for camera module price and more detailed introduction. SINCEREFIRST is a leading high-tech company specializing in integrated optical device manufacturers and optical imaging system solution providers. There are different types of camera modules and camera sensors for sale, and they also support customization to meet all your needs and solve your problems.
