Sony IMX989 50MP Large Sensor C-PHY Auto Focus FPC Camera Module
Guangzhou Sincere Information Technology Ltd. is one of the most professional Sony IMX989 50MP Large Sensor C-PHY Auto Focus FPC Camera Module manufacturers and suppliers in China. Welcome to wholesale discount products for sale here from our factory. Customized orders are welcome.
Developers searching for Sony IMX989 specifications often need to know more than what the image sensor can provide on its own. A practical camera design also depends on the lens, focusing structure, interface, connector and available mechanical space. This module integrates the 50MP IMX989 into a defined FPC camera configuration built around its large 1/0.98-inch sensor format.
The IMX989 provides 8192 × 6144 native resolution with 1.6 μm pixels and supports 4K@30FPS, 4-in-1 pixel operation, Octa-PD, HDR and 8/10/12/14-bit RAW output. The module adds VCM Auto Focus, a D87° × H72° × V57° optical configuration and a 30Pin BTB C-PHY MIPI interface. Active Alignment is used as the standard production process for this model.
Features
• 1/0.98-Inch Large Sensor Platform
The Sony IMX989 uses a 1/0.98-inch optical format with 1.6 μm pixels, making sensor size one of the main reasons to consider this module over smaller-format 50MP alternatives.
• 50MP Native Image Detail
The sensor provides 8192 × 6144 native resolution while the confirmed video output is 4K@30FPS, supporting projects that require high-resolution still-image acquisition as well as 4K video output.
• Octa-PD with VCM Auto Focus
The module combines the IMX989 Octa-PD capability with a VCM Auto Focus structure and a 13 cm to Infinity focusing range for devices that need to capture subjects at changing distances.
• 8/10/12/14-Bit RAW Output
Multi-bit RAW support provides several image-data depth options for downstream ISP development and image-processing pipelines.
• 30Pin C-PHY MIPI Integration
The 30Pin BTB C-PHY MIPI interface provides a defined host-side integration route for OEM devices using a compatible processor and board architecture.
• In-House Active Alignment Production
This standard model is produced using SincereFirst's own Active Alignment equipment. AA is used during camera module assembly as a manufacturing process rather than being treated as a feature of the IMX989 sensor itself.
Application of MIPI Camera Module
• High-Detail Handheld Imaging
The large sensor, 50MP native resolution and VCM Auto Focus can support handheld scanners, portable imaging tools and other devices that need detailed capture across changing subject distances.
• Smart Imaging Terminals
The C-PHY interface and Auto Focus structure can be evaluated for smart terminals, access equipment and embedded imaging systems that require a high-resolution camera within an integrated device.
• Document and Visual Capture
High native resolution and multi-bit RAW output make the module suitable for document capture stations, visual archiving equipment and other systems where retained image detail is important.
• OEM High-Resolution Imaging
The IMX989 module provides a defined large-sensor camera route for specialized imaging equipment where the host platform has sufficient mechanical space and processing capability for a 1/0.98-inch sensor configuration.
Product Details
|
Product Name |
8K Resolution AA Process MIPI Camera Module |
|
Sensor |
Sony IMX989 CMOS Sensor |
|
Pixel |
50MP |
|
Resolution |
8192x6144 |
|
Frame Rate |
4K@30FPS |
|
Sensor Size |
1/0.98 Inch |
|
Feature |
Octa-PD, HDR, 4-in-1 Pixel |
|
Output Format |
8/10/12/14-bit RAW |
|
Focusing Range |
13cm ~ Infinity |
|
EFL |
8.7mm ±5% |
|
F.NO |
1.9 ±5% |
|
FOV |
D87°*H72°*V57° |
|
Focus Type |
VCM Auto Focus |
|
TV Distortion |
＜1% |
|
Process |
Active Alignment (AA) Process - standard production |
|
Interface |
30Pin BTB C-PHY MIPI Interface |
Customization Options
Large-Sensor Mechanical Integration
The 1/0.98-inch sensor and optical stack require more installation space than smaller camera configurations. Module dimensions, lens clearance and enclosure layout can be discussed around the target device before the design is finalized.
C-PHY Host and Connector Matching
The 30Pin C-PHY route should be matched with the host processor, connector and board architecture. Available interface and connector information can be discussed during project integration.
Lens, FOV and Focus Configuration
The standard D87° × H72° × V57° view and 13 cm to Infinity focusing range can be reviewed when the target application needs different scene coverage or focusing behavior.
FPC and Module Structure
FPC layout and related mechanical requirements can be discussed for OEM devices where the standard structure does not directly match the available installation space.
AA for Related Camera Designs
This IMX989 model uses Active Alignment as standard production. Other suitable camera module designs can also be produced with AA as an additional paid manufacturing process when their optical requirements justify the added cost.
FAQ
Q: Why choose an IMX989 camera module instead of another 50MP camera module?
A: The main difference is the large 1/0.98-inch sensor format with 1.6 μm pixels. Projects that prioritize sensor size, high native image detail and a large-sensor optical configuration may prefer the IMX989 route over smaller-format 50MP alternatives.
Q: What are the main Sony IMX989 sensor specifications used in this module?
A: This configuration uses a 50MP Sony IMX989 CMOS sensor with 8192 × 6144 native resolution, a 1/0.98-inch sensor format and 1.6 μm pixels. It also supports 4-in-1 pixel operation, Octa-PD and HDR.
Q: Is this a complete IMX989 camera module or only the image sensor?
A: This is a complete FPC camera module configuration. It combines the IMX989 sensor with lens optics, VCM Auto Focus, FPC, connector and C-PHY MIPI integration.
Q: What interface does the IMX989 camera module use?
A: The confirmed interface is a 30Pin BTB C-PHY MIPI interface. Host processor compatibility, connector routing and board integration should be confirmed before final device development.
Q: What RAW formats are supported?
A: The confirmed image output formats include 8-bit, 10-bit, 12-bit and 14-bit RAW.
Q: What is the Auto Focus range?
A: The module uses VCM Auto Focus with a confirmed focusing range from 13 cm to Infinity.
Q: Can I request a sample and technical information before production?
A: Yes. Samples can be discussed for imaging and integration testing, and available module information such as connector, interface and mechanical details can be provided according to the project stage.
Q: Can the FPC, lens or camera structure be customized?
A: Customization can be discussed around the required FPC layout, optical configuration, connector and mechanical installation of the target device.
Evaluating IMX989 for a Large-Sensor Camera Design?
The 1/0.98-inch IMX989 offers a different design route from smaller 50MP camera modules, but it also places different demands on mechanical space, optics and host integration. Talk with SincereFirst to compare the IMX989 configuration with other 50MP options, review C-PHY integration or request a sample for project testing.
