IP67 720P CMOS USB Endoscope Camera Module For Internal Inspection
Guangzhou Sincere Information Technology Ltd. is one of the most professional ip67 720p cmos usb endoscope camera module for internal inspection manufacturers and suppliers in China. Welcome to wholesale discount products for sale here from our factory. Customized orders are welcome.
This camera module brings HD observation and protected-head construction together for internal inspection. Its 1MP CMOS imaging system provides 720P video at 18fps, while the IP67 camera head supports viewing in locations exposed to dust or water.
The forward-facing lens focuses best at 5cm. A 76° diagonal field of view covers the area ahead, and 6 white SMD LEDs illuminate nearby surfaces inside a cavity with little ambient light. These features support the main inspection task: seeing the condition of an internal surface from a close observation point.
The 6.35mm outer diameter helps the head enter restricted openings, and the integrated Steel Shell brings the lens and lighting into a protected assembly. USB2.0 provides the connection for incorporation into the inspection product.
Features
• IP67 Camera-Head Protection
The protected head supports inspection where dust or water is present around the observation point. The Steel Shell forms the outer structure of the integrated lens and lighting assembly.
• 720P Video for Close Surface Observation
1280 × 720 imaging at 18fps provides an HD view of nearby internal surfaces. This helps an operator examine visible assembly conditions, deposits or loose material through the inspection tool.
• Local Illumination with 6 White LEDs
Lighting around the forward lens reaches the area being observed. Bringing illumination to the head is useful inside cavities that receive little external light.
• Forward-View Optics for a Defined Observation Position
The Fixed Focus lens has a 5cm best-focus distance and D76° field of view. The 6.35mm head diameter supports access to the position from which the surface needs to be seen.
Application of Endoscope Camera Module
• Internal Equipment Surface Checks
View nearby internal walls, fittings and visible assembly conditions through an equipment opening. The 720P image and local LEDs support close visual examination, with an IP67 head for dusty or wet observation locations.
• Pipe and Channel Observation
Use the forward view to examine the area ahead inside a pipe or channel. The lens and lighting support looking at nearby surfaces from an accessible position.
• Assembly Inspection Tools
Incorporate the camera module into an instrument used to check internal assembly conditions. The integrated head puts the viewing lens and illumination together at the inspection end.
Product Details
|
Product Name |
Integrated USB Endoscope Camera Module |
|
Sensor |
CMOS Sensor |
|
Pixel |
1MP |
|
Resolution |
1280x720 |
|
Frame Rate |
1280x720@18FPS |
|
Sensor Size |
1/9" |
|
Focus Type |
Fixed Focus |
|
FOV |
D76° |
|
F.NO |
2.8 |
|
Working Distance |
5cm |
|
Lens Diameter |
6.35mm |
|
LED |
6 LEDs |
|
Protection |
With Steel Shell, Support IP67 |
|
Structure |
Integrated Design |
|
Interface |
USB2.0 |
Customization Options
Lens and working distance
Match the observation area and focus position to the surface inside the equipment.
Lighting configuration
Select LED quantity, layout, brightness and dimming options for the cavity and surface reflectivity.
Filter and illumination options
Match filters and, where required by the project, IR LED or no-LED configurations to the observation task.
Shell and mounting
Adapt the mechanical connection and mounting structure to the inspection instrument.
Cable and connector configuration
Match routing, length and connection details to the product.
USB software and output support
Provide SDK, firmware, driver and supported output configuration services for the selected host platform.
Project services
Certification support, production supply coordination and warranty service can be arranged for the agreed camera module configuration.
FAQ
Q: How should a forward-view module be positioned to examine a cavity wall?
A: The lens needs a view toward the surface being examined. The 5cm figure is its best-focus distance, so the observation position should place the important area around that distance. A side-view module is more appropriate when the required surface lies beside the head and cannot be viewed effectively from the front.
Q: How should lighting be selected for reflective metal surfaces?
A: Surface reflections depend on the lighting angle, brightness and lens position. Match the LED arrangement and dimming requirements to the surface so the inspection image reveals useful detail without relying on LED count alone.
Build a Protected HD Inspection Camera Module
SincereFirst provides camera module design and manufacturing support for inspection products. We can help combine the required viewing distance, lighting and mechanical arrangement into a 720P endoscope camera module suited to your observation task.
