Micro OmniVision OV9623 Color Sensor Wide Angle MIPI Camera Module

This is micro Omnivision OV9623 color sensor wide-angle MIPI camera module. It features a highly sensitive OV9623 sensor with 1MP pixel, resolution of 1280×800, and sensor size of 1/2.7 inches. Paired with a MIPI high-speed data transmission interface, it meets the high-definition imaging requirements of embedded devices. The module size is only 24.2mm×17.1mm, compact and easy to integrate. The F1.8 large aperture and 1.96mm focal length design, combined with a focusing range from 20cm to infinity, ensure clear images can be captured even in low-light conditions. Supports HDR imaging, effectively handling high-contrast scenes. It is also equipped with an ultra-wide-angle design, with DFOV166° and HFOV149°, achieving wide field of view and high dynamic range shooting. The manual focusing function offers flexible control and is suitable for scenarios such as security and industrial inspection.

• Portable Body Camera: Compact and small in size, it can clearly record the law enforcement process without affecting work efficiency.

• Industrial AOI Inspection Instrument: Precisely locate micron-level solder joints and automatically detect PCB board soldering defects by transmitting high-definition images to the analysis system.

•Intelligent Access Control System: By covering the unit door/elevator hall with a wide-angle lens, it can handle backlit and night environments, and achieve face recognition and behavior monitoring.
