Sony IMX586 4K 48MP Image Sensor Telephoto Lens MIPI Camera Module
Guangzhou Sincere Information Technology Ltd. is one of the most professional sony imx586 4k 48mp image sensor telephoto lens mipi camera module manufacturers and suppliers in China. Welcome to wholesale discount products for sale here from our factory. Customized orders are welcome.
This model is a 48MP Telephoto Lens MIPI camera module designed for projects that need high-resolution narrow-FOV imaging instead of wide-angle capture. Built around the Sony IMX586 CMOS sensor, it supports 8000 × 6000 resolution, 4K@30FPS video direction, 1/2-inch optical format, 0.8μm × 0.8μm pixel size, 4-in-1 pixel support, HDR and 8 / 10-bit RAW output. The module uses a Fixed Focus Telephoto Lens with 25mm EFL, D17.5° × H14° × V10.6° viewing angle and < 0.5% TV distortion. Its special-shaped FPC and 34Pin BTB MIPI interface make it suitable for compact devices requiring high-detail long-distance visual capture.
Features
• Sony IMX586 48MP Sensor
Provides 8000 × 6000 high-resolution capture for detailed imaging and narrow-FOV observation.
• Fixed Focus Telephoto Lens
The 25mm telephoto lens supports long-distance viewing where narrow scene coverage is required.
• Low Distortion Optical Design
TV distortion below 0.5% helps support more accurate image capture in inspection and observation projects.
• 8 / 10-Bit RAW Output
Supports RAW image output for host-side processing, image tuning and embedded vision workflows.
• Special-Shaped FPC Design
The non-standard FPC layout helps fit products with compact or irregular internal mechanical structures.
Application of MIPI Camera Module
• Long-Distance Visual Observation
Suitable for projects requiring narrow-FOV image capture of distant or fixed-position targets.
• Industrial Inspection Devices
Can support inspection products that need high-resolution image detail and low distortion.
• Compact Telephoto Imaging Systems
Works for embedded devices where wide-angle capture is not suitable and target detail matters more.
• AI Vision and Recognition Products
Can be evaluated for AI systems requiring high-resolution telephoto image input.
Product Details
|
Product Name |
Sony 4K Telephoto Lens Camera Module |
|
Sensor |
Sony IMX586 CMOS Sensor |
|
Pixel |
48MP |
|
Resolution |
8000x6000 |
|
Sensor Size |
1/2 Inch |
|
Output Format |
8 / 10-bit RAW |
|
Features |
HDR, 4-in-1 pixel support |
|
EFL |
25mm |
|
F.NO |
2.4 |
|
FOV |
D17.5° × H14° × V10.6° |
|
Structure |
Special-shaped FPC design |
|
TV Distortion |
< 0.5% |
|
Lens |
6G Telephoto Lens |
|
Interface |
34Pin BTB MIPI |
Customization Options
Telephoto Viewing Distance Matching
The Fixed Focus Telephoto Lens can be matched to target distance, object size and required image framing.
FPC Layout Adaptation
Special-shaped FPC routing, bending area and connector direction can be evaluated for compact device structures.
MIPI Connector Integration
34Pin BTB MIPI connection and pin definition can be checked according to the target host platform.
Low-Distortion Optical Configuration
Lens structure and FOV can be discussed for projects that need narrow-FOV imaging with low geometric distortion.
RAW Image Tuning Support
8 / 10-bit RAW output can be evaluated according to ISP processing, HDR behavior and final image quality needs.
FAQ
Q: What is SF-SC586-AERORA03 V1.0 designed for?
A: It is designed for high-resolution narrow-FOV imaging projects requiring an IMX586 telephoto MIPI camera module.
Q: Does this module use autofocus?
A: No. This model uses a Fixed Focus Telephoto Lens.
Q: What is the lens angle?
A: The lens angle is D17.5° × H14° × V10.6°.
Q: What is the focal length?
A: The EFL is 25mm.
Q: What output format does it support?
A: It supports 8 / 10-bit RAW output.
Q: Is it suitable for wide-angle applications?
A: No. This model is better for narrow-FOV telephoto observation and long-distance target capture.
Q: What should I provide for project evaluation?
A: Please provide target distance, object size, FOV requirement, host platform, connector type and mechanical layout.
