13MP Sony IMX258 4K PDAF USB2.0 Camera Module
Guangzhou Sincere Information Technology Ltd. is one of the most professional 13mp sony imx258 4k pdaf usb2.0 camera module manufacturers and suppliers in China. Welcome to wholesale discount products for sale here from our factory. Customized orders are welcome.
This is designed for embedded devices that need high-resolution image capture, autofocus control and compact 32mm × 32mm module integration. With a Sony IMX258 CMOS sensor, 4208 × 3120 resolution, PDAF support, VCM autofocus, D90.3° lens angle and TV distortion below -1%, this USB2.0 camera module is suitable for smart terminals, recognition systems, scanning devices and high-detail visual inspection applications.
• Sony IMX258 13MP Sensor
Provides 4208x3120 high-resolution imaging for applications requiring sharper visual detail.
• PDAF and VCM Autofocus
Supports phase detection and VCM autofocus for faster focusing in variable-distance scenes.
• Low-Distortion D90.3° Lens
Delivers wide scene coverage with TV distortion below -1% for cleaner image geometry.
• Compact 32mmx32mm Module
Uses a standard compact board size for easier integration into embedded devices and terminals.
• 1080P 30FPS Output
Supports 1080P video output at 30FPS for preview, testing and real-time visual applications.
• USB2.0 Interface Design
Provides practical USB integration for embedded devices that require high-resolution still image capture.
Application of USB Camera Module
• Smart Recognition Terminals
Suitable for face recognition, identity terminals and access control devices needing high-resolution autofocus.
• Document and Book Scanning
Supports detailed image capture for document scanning, book scanning and visual archiving devices.
• Barcode and QR Code Reading
Can be evaluated for scanning devices that require autofocus and clear close-range detail.
• Industrial and Object Inspection
Works for inspection equipment requiring high-pixel image capture and compact board integration.
Product Details
|
Product Name |
4K PDAF Embedded Camera Module |
|
Image Sensor |
Sony IMX258 CMOS sensor |
|
Pixel |
13MP |
|
Resolution |
4208x3120@10FPS, 1920x1080@30FPS |
|
Sensor Size |
1/3.06 Inch |
|
Focus Type |
PDAF + VCM Autofocus |
|
FOV |
D90°*H77.4°*V62° |
|
EFL |
2.8mm |
|
TV Distortion |
< -1% |
|
F.No |
1.9 |
|
Interface |
USB2.0 |
|
Module Size |
32mm*32mm |
Customization Options
Autofocus Behavior Review
PDAF and VCM autofocus behavior can be evaluated according to object distance, focusing speed and application workflow.
Lens and Low-Distortion FOV Review
Lens angle and optical performance can be reviewed according to target coverage, recognition distance and distortion requirement.
Optional 2-LED PCB Integration
Two LEDs can be optionally integrated on the PCB to support projects that need built-in illumination in a compact module structure.
32mm × 32mm Mechanical Layout Review
The compact board layout can be reviewed against product housing, mounting position and internal assembly space.
USB2.0 UVC Host-Side Evaluation
USB2.0 UVC output can be evaluated according to the host platform, software environment and image capture workflow.
FAQ
Q: What is the main positioning of this IMX258 camera module?
A: It is a compact 13MP autofocus USB camera module for high-resolution embedded imaging and recognition projects.
Q: Does this module support autofocus?
A: Yes. It supports PDAF and VCM autofocus for faster focusing in variable-distance applications.
Q: What is the maximum resolution?
A: The module supports 4208 × 3120 resolution.
Q: Can it output 1080P video at 30FPS?
A: Yes. It supports 1080P output at 30FPS.
Q: Is this module suitable for barcode or document scanning?
A: Yes. The 13MP resolution and autofocus design make it suitable for scanning and detail capture.
Q: Can the lens be customized?
A: Yes. Lens type, FOV, focus distance and optical structure can be adjusted according to project requirements.
Q: Can the connector or pin definition be changed?
A: Yes. Connector and pin definition adaptation can be reviewed for project-level integration.
Q: What information is needed before customization?
A: Please provide application, working distance, FOV, host system, mechanical limits and expected production quantity.
